Cooler Master CM 690 III

Cooler Master CM 690 III

Cooler Master CM 690 III

  • Full mesh on the front panel and top with large vents on the side panel for superior cooling
  • 3 designated places for radiators: 240mm: top, front; 120mm: rear
  • Supports up to three 200mm large fans for extreme  airflow with support for up to 9 total fans (KKN1: 9 fans, KWN1: 7 fans)

Add to my wishlist


Notify me when available

Customers who bought this product also bought:

27 other products in the same category:

More info

Introducing the new generation of iconic CM 690 series – CM 690 III!
CM 690 III is a revolutionary update to the popular CM 690 II mid-towers. The exterior retains the curved metal mesh look the series is known for. The interior has been completely updated – the HDD/SSD combo cage can be switched between 3.5-inch or 2.5-inch drives by adjustable trays without any screw. There's enough room for a 240mm liquid cooling radiator at the top or front, 120mm in the rear and supports up to 9 fans, including 3 large 200mm fans for extreme airflow. And cleaning is hassle free thanks to the multiple dust filters at the bottom, top, and front.



FEATURES



Removable top cover for easier installation and maintenance
Dual SuperSpeed USB 3.0; The cover protects I/O area and top compartment
Supports long VGAs up to 423mm / 16.6 inch
Removable HDD/SSD combo cage with adjustable HDD/SSD trays
Large slide-out dust filter for easy maintenance
Extra cable management space (27mm); Supports one SSD behind the M/B tray



COOLING





Supports a 240mm radiator at the top
Supports a 200mm fan at the top
Supports a 120mm radiator in the rear
Supports a 240mm radiator in the front
Supports two 120mm fans or one 180/200mm fan on the side panel (CMS-693-KKN1)
Includes a front 200mm fan for high airflow





AIRFLOW



● Top: 120/140mm fan x 2, or 200mm fan x 1 (optional)
● Front: 200mm fan x 1 (installed), or 120/140mm fan x 2 / 180mm fan x 1 (optional)
● Rear: 120mm fan x 1 (installed)
● Side: 120mm fan x 2 or 180/200mm fan x 1 (optional) – for CMS-693-KKN1
● Bottom: 120mm fan x 1 (optional)
● HDD cage: 120mm fan x 1 (optional)



MORE INFORMATION



Model NumberBlack: CMS-693-KKN1
          CMS-693-KWN1 (with side panel window)
Available ColorMidnight Black
MaterialsPolymer, mesh front bezel
Dimensions (W x H x D)230 x 507 x 502 mm / 9.1 x 20.0 x 19.8 inch
Net Weight8.9 kg / 19.6 lbs
M/B TypemicroATX, ATX
5.25" Drive Bays3 (exposed)
3.5" Drive Bays7 (hidden)
2.5" Drive Bays10 (hidden; 7 from the HDD/SSD combo cages, 1 under the ODD cage, 1 behind the M/B tray,1 at the bottom)
I/O PanelUSB 3.0 x 2, USB 2.0 x 2, Audio In & Out (supports AC97 / HD Audio)
Expansion Slots7+1
Cooling SystemTop: 120/140mm fan x 2, or 200mm fan x 1 (optional)
Front: 200mm fan x 1 (installed), or 120/140mm fan x 2 , 180mm fan x 1(optional)
Rear: 120mm fan x 1 (installed)
Side: 120mm fan x 2 or 180/200mm fan x 1(optional) - for CMS-693-KKN1 (standard version) only
Bottom: 120mm fan x 1 (optional)
HDD cage: 120mm fan x 1 (optional)
Power Supply TypeStandard ATX PS2
Maximum CompatibilityVGA card length: 423 mm / 16.6 inch
CPU cooler height: 171mm / 6.7 inch

Accessories
