Nepton 280L

Nepton 280L

Nepton 280L

  • Factory filled with coolant, then sealed and pressure tested - requires zero maintenance for years.
  • CM self-designed pump and water block guarantees the best water flow and system performance.

RL-N28L-20PK-R1

Add to my wishlist


Notify me when available

8 other products in the same category:

More info

  • Factory filled with coolant, then sealed and pressure tested - requires zero maintenance for years.
  • CM self-designed pump and water block guarantees the best water flow and system performance.
  • Bigger tubing and radiator size provide superior heat dissipation performance.
  • Exclusive Dual JetFlo 140 fans to dissipate large amounts of heat through the radiator.
  • Unique LED illumination on the water block lens.
ModelRL-N28L-20PK-R1 / RL-N28L-20PK-R2
CPU SocketIntel LGA 2011-3 / 2011 / 1366 / 1156 / 1155 / 1151 / 1150 / 775
AMD Socket FM2 / FM1 / AM3+ / AM3 / AM2
Waterblock Dimensions75 x 69.8 x 49.1 mm ( 3 x 2.7 x 1.9 inch )
Radiator Dimensions311 x 139 x 30 mm ( 12.2 x 5.5 x 1.2 inch )
Radiator MaterialAluminum
Tube Length375 mm
Tube DiameterΦ10
Fan Dimension140 x 140 x 25 mm ( 5.9 x 5.9 x 1 inch ) *support 120mm fan x 2
Fan Speed800~2000 RPM (PWM) ± 10%
Fan Airflow54~122.5 CFM ± 10%
Fan Air Pressure0.7~3.5 mm H2O ± 10%
Fan Life Expectancy40,000 hours
Fan Noise Level (dB-A)21~39 dBA
Bearing TypeRifle bearing
Connector4-Pin
Fan Rated Voltage12 VDC
Fan Rated Current0.3A
Power Consumption3.6W
Pump Life Expectancy70,000 hrs
Pump Noise<25 dBA
Pump Rated Voltage12 VDC
Pump Power2.9W
EAN / UPC Code4719512046159 / 884102025150
