Intel® Core™ i5-6402P Processor
(6M Cache, up to 3.40 GHz)

-EGP 270.00

EGP 3,450.00

On sale On sale!

EGP 3,180.00

Add to cart

Add to my wishlist

17 other products in the same category:

More info

Specifications

-
Essentials
StatusLaunched
Launch DateQ4'15
Processor Numberi5-6402P
Cache6 MB
DMI38 GT/s
Instruction Set64-bit
Instruction Set ExtensionsSSE4.1/4.2, AVX 2.0
Embedded Options AvailableNo
Lithography14 nm
Scalability1S Only
Thermal Solution SpecificationPCG 2015C (65W)
Recommended Customer PriceBOX : $187.00
TRAY: $182.00
Conflict FreeYes
DatasheetLink
-
Performance
# of Cores4
# of Threads4
Processor Base Frequency2.8 GHz
Max Turbo Frequency3.4 GHz
TDP65 W
-
Memory Specifications
Max Memory Size (dependent on memory type)64 GB
Memory TypesDDR4-1866/2133, DDR3L-1333/1600 @ 1.35V
Max # of Memory Channels2
Max Memory Bandwidth34.1 GB/s
ECC Memory Supported No
-
Graphics Specifications
Processor Graphics Intel® HD Graphics 510
Graphics Base Frequency350 MHz
Graphics Max Dynamic Frequency950 MHz
Graphics Video Max Memory64 GB
Graphics OutputeDP/DP/HDMI/DVI
4K SupportYes, at 60Hz
Max Resolution (Intel® WiDi)‡1080p
Max Resolution (HDMI 1.4)‡4096x2304@24Hz
Max Resolution (DP)‡4096x2304@60Hz
Max Resolution (eDP - Integrated Flat Panel)‡4096x2304@60Hz
Max Resolution (VGA)‡N/A
DirectX* Support12
OpenGL* Support4.4
Intel® Quick Sync VideoYes
Intel® InTru™ 3D TechnologyYes
Intel® Insider™Yes
Intel® Wireless DisplayYes
Intel® Clear Video HD TechnologyYes
Intel® Clear Video TechnologyYes
# of Displays Supported 3
Device ID0x1902
-
Expansion Options
PCI Express Revision3.0
PCI Express Configurations Up to 1x16, 2x8, 1x8+2x4
Max # of PCI Express Lanes16
-
Package Specifications
Max CPU Configuration1
TCASE71°C
Package Size37.5mm x 37.5mm
Graphics and IMC Lithography14 nm
Sockets SupportedFCLGA1151
Low Halogen Options AvailableSee MDDS
-
Advanced Technologies
Intel® Turbo Boost Technology 2.0
Intel® vPro Technology No
Intel® Hyper-Threading Technology No
Intel® Virtualization Technology (VT-x) Yes
Intel® Virtualization Technology for Directed I/O (VT-d) Yes
Intel® VT-x with Extended Page Tables (EPT) Yes
Intel® TSX-NINo
Intel® 64 Yes
Idle StatesYes
Enhanced Intel SpeedStep® TechnologyYes
Thermal Monitoring TechnologiesYes
Intel® Identity Protection Technology Yes
Intel® Stable Image Platform Program (SIPP)No
Intel® Small Business AdvantageYes
-
Intel® Data Protection Technology
Intel® AES New InstructionsYes
Secure KeyYes
Intel® Software Guard Extensions (Intel® SGX)Yes
Intel® Memory Protection Extensions (Intel® MPX)Yes
-
Intel® Platform Protection Technology
OS GuardYes
Trusted Execution Technology No
Execute Disable Bit Yes
