i5-7500 Processor

i5-7500 Processor

i5-7500 Processor

(6M Cache, up to 3.80 GHz)

BX80677I57500

-EGP 100.00

EGP 3,850.00

Reduced price!

EGP 3,750.00

Add to cart

Add to my wishlist

17 other products in the same category:

More info

Specifications

-
Essentials
Processor Numberi5-7500
StatusLaunched
Launch DateQ1'17
Lithography14 nm
Recommended Customer Price$192.00 - $202.00
-
Performance
# of Cores4
# of Threads4
Processor Base Frequency3.40 GHz
Max Turbo Frequency3.80 GHz
Cache6 MB SmartCache
Bus Speed8 GT/s DMI3
# of QPI Links0
TDP65 W
-
Supplemental Information
Embedded Options AvailableYes
Conflict FreeYes
DatasheetLink
-
Memory Specifications
Max Memory Size (dependent on memory type)64 GB
Memory TypesDDR4-2133/2400, DDR3L-1333/1600 @ 1.35V
Max # of Memory Channels2
ECC Memory Supported No
-
Graphics Specifications
Processor Graphics Intel® HD Graphics 630
Graphics Base Frequency350.00 MHz
Graphics Max Dynamic Frequency1.10 GHz
Graphics Video Max Memory64 GB
4K SupportYes, at 60Hz
Max Resolution (HDMI 1.4)‡4096x2304@24Hz
Max Resolution (DP)‡4096x2304@60Hz
Max Resolution (eDP - Integrated Flat Panel)‡4096x2304@60Hz
DirectX* Support12
OpenGL* Support4.4
Intel® Quick Sync VideoYes
Intel® InTru™ 3D TechnologyYes
Intel® Clear Video HD TechnologyYes
Intel® Clear Video TechnologyYes
# of Displays Supported 3
Device ID0x5912
-
Expansion Options
Scalability1S Only
PCI Express Revision3.0
PCI Express Configurations Up to 1x16, 2x8, 1x8+2x4
Max # of PCI Express Lanes16
-
Package Specifications
Sockets SupportedFCLGA1151
Max CPU Configuration1
Thermal Solution SpecificationPCG 2015C (65W)
TJUNCTION100°C
Package Size37.5mm x 37.5mm
Low Halogen Options AvailableSee MDDS
-
Advanced Technologies
Intel® Turbo Boost Technology 2.0
Intel® vPro Technology Yes
Intel® Virtualization Technology (VT-x) Yes
Intel® Virtualization Technology for Directed I/O (VT-d) Yes
Intel® TSX-NIYes
Intel® 64 Yes
Instruction Set64-bit
Instruction Set ExtensionsSSE4.1/4.2, AVX 2.0
Idle StatesYes
Enhanced Intel SpeedStep® TechnologyYes
Thermal Monitoring TechnologiesYes
Intel® Identity Protection Technology Yes
Intel® Stable Image Platform Program (SIPP)Yes
-
Intel® Data Protection Technology
Intel® AES New InstructionsYes
Secure KeyYes
Intel® Software Guard Extensions (Intel® SGX)Yes
Intel® Memory Protection Extensions (Intel® MPX)Yes
-
Intel® Platform Protection Technology
OS GuardYes
Trusted Execution Technology Yes
Execute Disable Bit Yes
Intel® Device Protection Technology with Boot GuardYes
