Intel® Core™ i5-7400 Processor

6M Cache, up to 3.50 GHz

-EGP 210.00

EGP 3,400.00

Reduced price!

EGP 3,190.00

Add to cart

Add to my wishlist

25 other products in the same category:

More info

                           ARK | Compare Intel® Products
                     3/15/2017 6:26:57 AM
Intel® Core™ i5-7400 Processor (6M Cache, up to 3.50 GHz)
Code NameKaby Lake
Essentials
Vertical SegmentDesktop
Processor Numberi5-7400
StatusLaunched
Launch DateQ1'17
Lithography14 nm
Recommended Customer Price$182.00
Performance
# of Cores4
# of Threads4
Processor Base Frequency3.00 GHz
Max Turbo Frequency3.50 GHz
Cache6 MB SmartCache
Bus Speed8 GT/s DMI3
# of QPI Links0
TDP65 W
Supplemental Information
Embedded Options AvailableNo
Conflict FreeYes
DatasheetLink
Memory Specifications
Max Memory Size (dependent on memory type)64 GB
Memory TypesDDR4-2133/2400, DDR3L-1333/1600 @ 1.35V
Max # of Memory Channels2
ECC Memory Supported   ‡No
Graphics Specifications
Processor Graphics ‡Intel® HD Graphics 630
Graphics Base Frequency350.00 MHz
Graphics Max Dynamic Frequency1.00 GHz
Graphics Video Max Memory64 GB
4K SupportYes, at 60Hz
Max Resolution (HDMI 1.4)‡4096x2304@24Hz
Max Resolution (DP)‡4096x2304@60Hz
Max Resolution (eDP - Integrated Flat Panel)‡4096x2304@60Hz
DirectX* Support12
OpenGL* Support4.4
Intel® Quick Sync VideoYes
Intel® InTru™ 3D TechnologyYes
Intel® Clear Video HD TechnologyYes
Intel® Clear Video TechnologyYes
# of Displays Supported ‡3
Device ID0x5912
Expansion Options
Scalability1S Only
PCI Express Revision3.0
PCI Express Configurations ‡Up to 1x16, 2x8, 1x8+2x4
Max # of PCI Express Lanes16
Package Specifications
Sockets SupportedFCLGA1151
Max CPU Configuration1
Thermal Solution SpecificationPCG 2015C (65W)
T<sub>JUNCTION</sub>100°C
Package Size37.5mm x 37.5mm
Low Halogen Options AvailableSee MDDS
Advanced Technologies
Intel® Optane™ Memory Supported ‡Yes
Intel® Turbo Boost Technology2.0
Intel® vPro Technology ‡No
Intel® Virtualization Technology (VT-x) ‡Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡Yes
Intel® VT-x with Extended Page Tables (EPT) ‡Yes
Intel® TSX-NIYes
Intel® 64 ‡Yes
Instruction Set64-bit
Instruction Set ExtensionsSSE4.1/4.2, AVX 2.0
Idle StatesYes
Enhanced Intel SpeedStep® TechnologyYes
Thermal Monitoring TechnologiesYes
Intel® Identity Protection Technology ‡Yes
Intel® Stable Image Platform Program (SIPP)No
Intel® Data Protection Technology
Intel® AES New InstructionsYes
Secure KeyYes
Intel® Software Guard Extensions (Intel® SGX)Yes
Intel® Memory Protection Extensions (Intel® MPX)Yes
Intel® Platform Protection Technology
OS GuardYes
Execute Disable Bit ‡Yes
Intel® Device Protection Technology with Boot GuardYes

Data sheet

  • Soket - 1151
