DCS-2103 HD Cube Network Camera

DCS-2103 HD Cube Network Camera

DCS-2103 HD Cube Network Camera

The DCS-2103 is a unique and versatile HD quality surveillance solution for your home or small office

Warning: Last items in stock!

DCS-2103

EGP 1,400.00

Add to cart

Add to my wishlist

11 other products in the same category:

More info

The DCS-2103 is a unique and versatile surveillance solution for your home or small office. Unlike a traditional webcam, the DCS-2103 is a complete system with a built-in CPU and web server that transmits high quality video images for security and surveillance. Simple installation and an intuitive web-based interface offer easy integration with your Ethernet .The DCS-2103 also comes with remote monitoring and motion detection features for a complete and cost-effective home security solution.

  • 1/4” 1 Megapixel CMOS progressive sensor
  • Real-time H.264, MPEG-4 and Motion JPEG Compression
  • HD resolution (1280x720) and up to 1M (1280x800)
  • Fixed lens 3.45 mm F2.0
  • Simultaneous multi-stream support ePTZ
  • Supports multiple access list
  • Privacy Mask feature
  • Micro SD Card slot
  • 2-way audio support
  • 1 digital input / 1 digital output
  • 3GPP mobile surveillance
echnical Specifications
Camera Hardware Profile1/4” 1 Megapixel progressive CMOS sensor
Minimum illumination: 1.0 lux
10x digital zoom
Fixed length 3.45 mm
Aperture: F2.0
Angle of view:
(H) 57.8°
(V) 37.8°
(D) 66°
Video CompressionSimultaneous H.264/MPEG-4/MJPEG format compression
JPEG for still images
Audio Support G.726
External Device Interfaces1 DI / 1 DO
MicroSD card slot
Built-in microphone
3.5 mm audio output jack
SecurityAdministrator and user group protection
Password authentication
Event ManagementMotion detection
Event notification and upload snapshots/video clips via HTTP, SMTP, or FTP
Supports multiple HTTP, SMTP, and FTP servers
Multiple event notifications
Multiple recording methods for easy backup
D-ViewCam™ Software FunctionsRemote management/control of up to 32 cameras
Viewing of up to 32 cameras on one screen
Supports all management functions provided in web interface
Scheduled motion triggered, or manual recording options
Max. Power ConsumptionDCS-2103: 2 watts
Operating Temperature0 to 40 °C (32 to 104 °F)
Storage Temperature-20 to 70 °C (-4 to 158 °F)
Humidity20% to 80% non-condensing
