TVS-EC1080+

TVS-EC1080+

TVS-EC1080+

QNAP TVS-EC1080+, featuring the easy-to-use QTS operating system, provides a reliable and scalable NAS solution to fulfill data backup, file synchronization and remote access. The TVS-EC1080+ features built-in dual-port 10GbE and 256GB mSATA modules, delivers exceptional

TVS-EC1080+

Add to my wishlist


Notify me when available

14 other products in the same category:

More info

QNAP TVS-EC1080+, featuring the easy-to-use QTS operating system, provides a reliable and scalable NAS solution to fulfill data backup, file synchronization and remote access. The TVS-EC1080+ features built-in dual-port 10GbE and 256GB mSATA modules, delivers exceptional performance, and supports cross-platform file sharing, comprehensive backup solutions, iSCSI and virtualization applications, and many practical business functions, making it the ideal choice for SMBs to secure important business data. It also includes abundant multimedia applications backed by its powerful hardware specifications.

  • 2,000+ MB/s throughput and 223,000+ IOPS
  • Built-in 256GB mSATA modules and up to 4 SSDs for caching, beneficial to IOPS demanding applications
  • Enjoy 4K2K UHD videos HDMI local display and transcoding with new HD Station 2.0
  • Monitor and manage multiple QNAP Turbo NAS with Q’center Multi-NAS management system
  • Use the TVS-EC1080+ as a PC with exclusive QvPC Techonology
  • Virtualization-ready, centralized data storage, backup, sharing and disaster recovery

CPU

Intel® Xeon® E3-1245 v3 3.4 GHz Quad Core Processor or above
MemorySystem memory: 32 GB DDR3 RAM (non-ECC Memory)
Memory module pre-installed: 8 GB x4
Total memory slots: 4
Flash Memory512MB DOM
Internal Cache PortBuilt-in 256GB (128GB*2) mSATA module for caching
Hard Drive10 x 3.5-inch SATA 6Gbps/3Gbps hard drive or 2.5-inch SATA, 6Gbps/3Gbps hard drive SSD hard drive
NOTE:
  1. The standard system is shipped without hard drives.
  2. For the hard drive compatibility list, please visit https://www.qnap.com/compatibility
Hard Drive Tray10 x hot-swappable and lockable tray
LAN Port2 x 10 Gigabit RJ-45 Ethernet port ( Pre-installed in PCIe slot)
4 x 1 Gigabit RJ-45 Ethernet port (on board)

Note:
1. For the optional network card compatibility list, please visit Compatibility list
2. For the information of network card installation, please refer to chapter 6 in the Turbo NAS Hardware Manual.
LED IndicatorsStatus, LAN, USB, eSATA and 10 GbE
USB3x USB 3.0 port (1 front, 2 rear)
6x USB 2.0 port (rear)
Support USB printer, pen drive, USB hub, and USB UPS etc.
ButtonsSystem: Power button and reset button
Alarm BuzzerSystem warning
Form FactorTower
Dimensions217.5(H) x 327(W) x 321.2(D) mm
8.56(H) x 12.8(W) x 12.65(D) inch
WeightNet weight (NAS only) : 12.52 kg/27.61 lb
Gross weight (with packing and accessories) : 19.75 kg/43.54 lb
Sound Level (dB)Standby: 30.4 dB
In operation: 31.6 dB
(with 10 x 1TB hard drives installed)
Power Consumption (W)Sleep mode: 68W
In Operation: 130W
(with 10 x 1TB hard drives installed)
Temperature0-40˚C
Relative Humidity5~95% non-condensing, wet bulb: 27˚C.
Power SupplyInput: 100-240V AC, 50/60Hz, Output: 350W
PCIe Slot1* PCIe Gen3 x8 ( Pre-installed with QNAP LAN-10G2T-X550 dual-port 10 Gigabit Network card)
Fan2 x 12 cm smart cooling fan

1.LED Indicators:
Status, LAN, USB, eSATA, 10 GbE, LAN
10.10 Gigabit Port x2
2.HDD Status LED11.USB 2.0 Port x6
3.Select Button12.Password & Network Settings Reset Button
4.Enter Button13.HDMI x1
5.Tray Lock14.USB 3.0 Port x2
6.Tray Release Button15.K-Lock Security Slot
7.One Touch Copy Button/ USB 3.0 Port16.Gigabit LAN Port x4
8.Power Button17.Power Connector
9.eSATA Port x2
