Kingston DDR4 2133MHz

Kingston DDR4 2133MHz

Kingston DDR4 2133MHz

Kingston® offers extremely reliable, high-performance ValueRAM desktop memory, ideal for those looking for the best value in industry-standard memory.

EGP 1,190.00

Add to cart

Add to my wishlist

12 other products in the same category:

More info

specifications are as follows:
CL(IDD)
Row Cycle Time (tRCmin)
Refresh to Active/Refresh
Command Time (tRFCmin)
Row Active Time (tRASmin)
Maximum Operating Power
UL Rating
Operating Temperature
Storage Temperature
15 cycles
46.5ns(min.)
260ns(min.)
33ns(min.)
TBD W*
94 V - 0
0o C to +85o C
-55o C to +100o C

FEATURES

• Power Supply: VDD=1.2V Typical
• VDDQ = 1.2V Typical
• VPP - 2.5V Typical
• VDDSPD=2.2V to 3.6V
• Nominal and dynamic on-die termination (ODT) for
data, strobe, and mask signals
• Low-power auto self refresh (LPASR)
• Data bus inversion (DBI) for data bus
• On-die VREFDQ generation and calibration
• Dual-rank
• On-board I2 serial presence-detect (SPD) EEPROM
• 16 internal banks; 4 groups of 4 banks each
• Fixed burst chop (BC) of 4 and burst length (BL) of 8
via the mode register set (MRS)
• Selectable BC4 or BL8 on-the-fly (OTF)
• Fly-by topology
• Terminated control command and address bus
• PCB: Height 1.23” (31.25mm)

Data sheet

  • Memory Type - DDR4
  • Form Factor - DIMM (PC)
