ELO 17-inch Multifunction Desktop

ELO 17-inch Multifunction Desktop

ELO 17-inch Multifunction Desktop

The 1717L touchmonitor is built to withstand the rigors of continuous public use with a rugged "built for touch" design

1717L

Add to my wishlist


Notify me when available

3 other products in the same category:

More info

The 1717L touchmonitor is built to withstand the rigors of continuous public use with a rugged "built for touch" design. Its stylish, thin and modern look is coupled with a retail-focused feature set and is an attractive solution for commercial touchmonitor needs. It is well suited for high use public venues where point-of-sale, point-of-information, point-of-service, shelf-level and countertop interactive digital signage and loyalty systems systems are found.

The 1717L is offered with AccuTouch five-wire resistive technology, IntelliTouch surface acoustic wave, or iTouch pure glass surface acoustic wave technology. AccuTouch is widely used in retail and hospitality environments based on its proven ability to survive splashing liquids, food and grease. IntelliTouch and iTouch pure glass surface acoustic wave technology delivers the ultimate in optical quality for dry retail and hospitality applications.

The optional 3-track magnetic stripe reader (MSR), programmable to either HID or Keyboard Emulation, is easily installed by the user, providing an elegant, integrated solution and eliminating the need for external brackets or attachments.

The 1717L touchmonitor is environmentally friendly, lightweight and uses less power with state-of-the-art LED backlights in the display panel.

Data Sheet

  • Sleek and thin design with “Built for Touch” Reliability.
  • Flexible and space-saving.
  • 40% Energy savings using LED technology.
  • Zero-bezel touchscreen versions for a smooth, easy-to-clean surface.
  • Antiglare or Clear glass.
  • Removable base and mounting options including VESA, wall and pole-mounting for installation flexibility and capped through-mount holes on base for table-top security.
  • 17” diagonal active matrix TFT LED-backlit LCD.
  • Active Display Area: 13.3 x 10.6 inches/338 x 270 mm.
  • 5:4 aspect ratio.
  • 1280 x 1024 native resolution. Other resolutions supported.
  • USB and RS232 serial connections.
  • Touch technology: AccuTouch (single- touch), IntelliTouch (single-touch) and iTouch (single-touch).
  • Typical power consumption: 20W, internal and external power options.
  • Warranty: 3 years standard.
Model1717L
ColorBlack or White
LCD TechnologyActive matrix TFT LCD with LED backlighting
Diagonal size17.0"
Monitor thickness1.7 inches/43 mm panel depth
Aspect Ratio5:4
Active Display Area13.3 x 10.6 inches/338 x 270 mm
Native Resolution1280 x 1024
Preset Video Timings

640x480 @ 60Hz, 75Hz
720x400 @ 70Hz
800x600 @ 56Hz, 60Hz, 75Hz
1024x768 @ 60Hz, 75Hz
1280x1024 @ 60Hz, 75Hz

Colors16.7 million
Brightness
(Typical)

LCD panel: 250 nits
with AccuTouch: 200 nits
with IntelliTouch: 225 nits
with iTouch: 225 nits

Response Time
(Tr+tf) (Typical)
5 msec
Viewing Angle
(Typical)
Horizontal: ±85° or 170° total
Vertical: ±80° or 160° total
Contrast Ratio (Typical)800:1
On-Screen Display (OSD)

Accessible through switches along the bottom:
Controls: Menu, Up, Down, Select
Settings:  Contrast, Brightness, H position, V-Position, Auto-Adjust, Aspect Ratio, Sharpness, Color, Temperature, Clock, Phase, OSD timeout, OSD Language, Recall, Defaults
Languages: English, French, Italian, German, Spanish, Japanese, Traditional Chinese, Simplified Chinese
Lockouts:  OSD, Power

Video• Analog VGA on Female DE-15 connector
Input Video Horizontal Sync frequency range: 31.5- 80KHz
Input Video Vertical Sync (frame rate) frequency range: 56-75Hz
Touch InterfaceSerial (RS232) and USB
Monitor input power connector – ACIEC 60320 C6
Monitor input power signal specifications100-240VAC, 50/60Hz
Monitor input power connector - DCCoaxial power jack (2.1mm pin outer diameter, 6.4mm barrel inner diameter)
Monitor input power signal specifications12VDC ±5%
NoteOptional AC-DC power adapter sold for this monitor
Adapter input connectorIEC 60320 C14
Adapter input voltage range100-240VAC, 50/60Hz
Power Consumption (Typical)ON (monitor only): 20W
SLEEP (monitor only) : 1.8W
OFF (monitor only) : 1.4W
Shipping Dimensions20.1 x 9.2 x 20 inches/511 x 233 x 510 mm
Dimensions
(with stand)
15.4 x 7.5 x 14.2 inches/392 x 215 x 361 mm
WeightUnpackaged: 11.9 lb/ 5.4 kg
Packaged: 18.3lb/ 8.3 kg
TemperatureOperating: 32°F to 104°F (0°C to 40°C)
Storage: -4°F to 140°F (20°C to 60°C)
Humidity
(noncondensing)
Operating: 20%-80%
Storage: 10%-90%
MTBF50,000 hours demonstrated
Mounting Options75 mm VESA mount
Capped through-mount holes
SealingTouchscreen sealed to bezel
Touchscreen sealed to LCD
Other FeaturesSecurity lock receptacle

Windows is a trademark of the Microsoft Corporation.

MTBF (Mean Time Between Failures)

An MTBF measurement is based on a statistical sample and is not intended to predict any one specific unit's reliability; thus MTBF is not, and should not be construed as, a warranty measurement.
