Sollatek stabilisation Wall mountable With Digital display

Sollatek stabilisation Wall mountable With Digital display

Sollatek stabilisation Wall mountable With Digital display

Single phase model for the Telecommunications and IT applications

DISPLAY Digital display of input voltage and output voltage
Technology

FULLY ELECTRONIC Stabiliser with
very wide input range (±20%)
and very narrow output range (±3%).

SVS45-22 10.5KVA

EGP 15,231.00

Add to cart

Add to my wishlist

22 other products in the same category:

More info

Description

THE SOLLATEK VOLTAGE STABILISER (SOLLATEK SVS) has been
designed to provide a clean, regulated AC power supply to all
equipment in environments with unreliable, fluctuating mains
electricity supplies.

OPERATION
The Sollatek SVS monitors the mains voltage continuously. If
the voltage rises or drops, the SVS will stabilise the output to
ensure the voltage reaching your equipment remains constant
at 230V, within the operating range of the unit.
APPLICATIONS
The SVS is suitable for all electrical and electronic appliances.
It is particularly useful for the following: Fridges, Air conditioners,
Freezers, Coolers, TV/HiFi, IT Equipment including computers,
Medical Refrigeration, and Telecom Equipment.
FEATURES
• Microprocessor controlled stabiliser
• Very wide input voltage range
• Excellent output voltage stability
• Includes surge and spike suppression
• Extremely fast response
• British design

THE SOLLATEK SVS HAS THE FOLLOWING
ADVANCED FEATURES :
• The Sollatek SVS reduces high voltage.
• Has a very wide voltage response range of 150V to 300V.
• Uses a unique zero voltage switching technique to
achieve clean pure stabilised power.
• Digital display of input voltage, output voltage
• Incorporates full spike protection.
• Frequency compensated measurements.
• Frequency and voltage measurement smoothing in
software to filter noise.

AMPS   45
kVA @ 230V   10.4KVA
Regulation ra nge
Input 230V ± 20% (184-276V)
Output 230V ± 3%
Frequency 45-75Hz
Spike Protection 800J, 6500 Amps (8/20μs). Response time <10 ns
Output C urr ent 45A RMS @ 45ºC
DISPLAY Digital display of input voltage and output voltage
Technology
Zero Voltage Switching Transformer tap switching takes place at zero point in voltage waveform
Response time Within 0.1 second
Performa nce
Thermal endurance Continuously rated at full load at full boost (full boost represents worst case)
Over-voltage endurance Runs continuously without damage at 300V input
EFFICIENC Y >96%
GROSS Weight 35 kg
QUANTIT Y PER 20’ CONT AINE R 132
QUANTIT Y PER 40’ CONT AINE R 264
Dimensions 345 x 330 x 260

Data sheet
